Description
FIXED IND 10NH 510MA 150 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MWSD1005C10NGT.
MWSD1005C10NGT has an inductance value of 10 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MWSD1005C10NGT is rated for 510 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MWSD1005C10NGT lists a DC resistance of 150mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MWSD1005C10NGT uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MWSD1005C10NGT to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 10 nH |
| Tolerance | ±2% |
| Current Rating | 510 mA |
| DC Resistance (DCR) | 150mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.043" L x 0.024" W (1.10mm x 0.60mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | Sunlord |
| Description | FIXED IND 10NH 510MA 150 MOHM |
| Series | MWSD-C |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 24 @ 250MHz |
| Self Resonant Frequency | 5.5GHz |
| Inductance Test Frequency | 250 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.026" (0.65mm) |
