FIXED IND 1.8NH 950MA 43 MOHM
| Inductance | 1.8 nH |
| Tolerance | ±5% |
| Current Rating | 950 mA |
| DC Resistance (DCR) | 43mOhm Max |
| saturationCurrent | - |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.043" L x 0.024" W (1.10mm x 0.60mm) |
| Case / Size | 0402 (1005 Metric) |
| Supplier | Shenzhen Sunlord Electronics Co., Ltd. |
| Description | FIXED IND 1.8NH 950MA 43 MOHM |
| Series | MWSD-C |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ceramic |
| shielding | Unshielded |
| qFactor | 20 @ 250MHz |
| selfResonantFreq | 6GHz |
| ratings | - |
| testFrequency | 250 MHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 0402 |
| heightMax | 0.026" (0.65mm) |
| features | - |
