Description
FIXED IND 5.1NH 620MA 100 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MWSD1005C5N1ST.
MWSD1005C5N1ST has an inductance value of 5.1 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MWSD1005C5N1ST is rated for 620 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MWSD1005C5N1ST lists a DC resistance of 100mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MWSD1005C5N1ST uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MWSD1005C5N1ST to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 5.1 nH |
| Tolerance | ±0.3nH |
| Current Rating | 620 mA |
| DC Resistance (DCR) | 100mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.043" L x 0.024" W (1.10mm x 0.60mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | Sunlord |
| Description | FIXED IND 5.1NH 620MA 100 MOHM |
| Series | MWSD-C |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 23 @ 250MHz |
| Self Resonant Frequency | 6GHz |
| Inductance Test Frequency | 250 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.026" (0.65mm) |
