Description
FIXED IND 1.5UH 7.99A 7.2 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for NS10145T1R5NNA.
NS10145T1R5NNA has an inductance value of 1.5 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
NS10145T1R5NNA is rated for 7.99 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
NS10145T1R5NNA lists a DC resistance of Pending manufacturer verification / 待原厂核实. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
NS10145T1R5NNA uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from NS10145T1R5NNA to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 1.5 µH |
| Tolerance | ±30% |
| Current Rating | 7.99 A |
| DC Resistance (DCR) | Pending manufacturer verification / 待原厂核实 |
| Saturation Current | 10.34A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.398" L x 0.398" W (10.10mm x 10.10mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Taiyo Yuden |
| Description | FIXED IND 1.5UH 7.99A 7.2 OHM |
| Series | NS |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 72.1MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.191" (4.85mm) |
