Description
FIXED IND 270NH 41A 0.29 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PA4060.271HLT.
PA4060.271HLT has an inductance value of 270 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PA4060.271HLT is rated for 41 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PA4060.271HLT lists a DC resistance of 0.29mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PA4060.271HLT uses a package or case of Nonstandard, 2 Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PA4060.271HLT to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 270 nH |
| Tolerance | ±15% |
| Current Rating | 41 A |
| DC Resistance (DCR) | 0.29mOhm |
| Saturation Current | 41A |
| Operating Temperature | -40°C ~ 130°C |
| Dimensions | 0.409" L x 0.315" W (10.40mm x 8.00mm) |
| Case / Size | Nonstandard, 2 Lead |
| Package / Case | Nonstandard, 2 Lead |
| Supplier | Pulse Electronics |
| Description | FIXED IND 270NH 41A 0.29 MOHM |
| Series | PA4060.XXXHL |
| Product Status | Active |
| Type / Construction | - |
| Core Material | - |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.295" (7.50mm) |
| Features | - |
