Description
FIXED IND 470UH 1.6A 1.43 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PA4310.474NLT.
PA4310.474NLT has an inductance value of 470 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PA4310.474NLT is rated for 1.6 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PA4310.474NLT lists a DC resistance of Pending manufacturer verification / 待原厂核实. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PA4310.474NLT uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PA4310.474NLT to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 470 µH |
| Tolerance | ±20% |
| Current Rating | 1.6 A |
| DC Resistance (DCR) | Pending manufacturer verification / 待原厂核实 |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.504" L x 0.504" W (12.80mm x 12.80mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 470UH 1.6A 1.43 OHM |
| Series | PA4310.XXXNL |
| Product Status | Active |
| Type / Construction | Wirewound |
| Shielding | Unshielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.315" (8.00mm) |
