Description
FIXED IND 6.8UH 2.12A 52 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PA4318.682NLT.
PA4318.682NLT has an inductance value of 6.8 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PA4318.682NLT is rated for 2.12 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PA4318.682NLT lists a DC resistance of 52mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PA4318.682NLT uses a package or case of Nonstandard, Corner Terminals. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PA4318.682NLT to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 6.8 µH |
| Tolerance | ±20% |
| Current Rating | 2.12 A |
| DC Resistance (DCR) | 52mOhm Max |
| Saturation Current | 1.8A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.240" L x 0.240" W (6.10mm x 6.10mm) |
| Case / Size | Nonstandard, Corner Terminals |
| Package / Case | Nonstandard, Corner Terminals |
| Supplier | Pulse Electronics |
| Description | FIXED IND 6.8UH 2.12A 52 MOHM |
| Series | PA4318 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.126" (3.20mm) |
