Description
FIXED IND 100UH 310MA 2.02 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PA4336.104NLT.
PA4336.104NLT has an inductance value of 100 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PA4336.104NLT is rated for 310 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PA4336.104NLT lists a DC resistance of 2.02Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PA4336.104NLT uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PA4336.104NLT to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 100 µH |
| Tolerance | ±20% |
| Current Rating | 310 mA |
| DC Resistance (DCR) | 2.02Ohm Max |
| Saturation Current | 480mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.157" L x 0.157" W (4.00mm x 4.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 100UH 310MA 2.02 OHM |
| Series | PA4336.XXXNLT |
| Product Status | Active |
| Core Material | Iron |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.079" (2.00mm) |
