Description
FIXED IND 100UH 300MA 3 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PAS1225V-101K.
PAS1225V-101K has an inductance value of 100 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PAS1225V-101K is rated for 300 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PAS1225V-101K lists a DC resistance of 3Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PAS1225V-101K uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PAS1225V-101K to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 100 µH |
| Tolerance | ±10% |
| Current Rating | 300 mA |
| DC Resistance (DCR) | 3Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.457" L x 0.150" W (11.60mm x 3.80mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | TAI-TECH |
| Description | FIXED IND 100UH 300MA 3 OHM SMD |
| Series | PAS1225V |
| Product Status | Active |
| Shielding | Unshielded |
| Q @ Frequency | 20 @ 125kHz |
| Self Resonant Frequency | 20MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 125 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.110" (2.80mm) |
