Description
FIXED IND 4.7UH 16.8A 4.5 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PB2020.472NLT.
PB2020.472NLT has an inductance value of 4.7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PB2020.472NLT is rated for 16.8 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PB2020.472NLT lists a DC resistance of 4.5mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PB2020.472NLT uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PB2020.472NLT to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 4.7 µH |
| Tolerance | ±20% |
| Current Rating | 16.8 A |
| DC Resistance (DCR) | 4.5mOhm Max |
| Saturation Current | 28A |
| Operating Temperature | -40°C ~ 130°C |
| Dimensions | 0.940" L x 0.820" W (23.87mm x 20.83mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 4.7UH 16.8A 4.5 MOHM |
| Series | PB2020NL |
| Product Status | Active |
| Type / Construction | Wirewound |
| Shielding | Unshielded |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.400" (10.16mm) |
