Description
FIXED IND 118UH 200MA 1.8 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PE-53803NL.
PE-53803NL has an inductance value of 118 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PE-53803NL is rated for 200 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PE-53803NL lists a DC resistance of 1.8Ohm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PE-53803NL uses a package or case of Radial, Vertical - Corner Terminals. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PE-53803NL to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 118 µH |
| Tolerance | ±20% |
| Current Rating | 200 mA |
| DC Resistance (DCR) | 1.8Ohm |
| Operating Temperature | -40°C ~ 130°C |
| Dimensions | 0.360" L x 0.360" W (9.14mm x 9.14mm) |
| Case / Size | Radial, Vertical - Corner Terminals |
| Package / Case | Radial, Vertical - Corner Terminals |
| Supplier | Pulse Electronics |
| Description | FIXED IND 118UH 200MA 1.8 OHM TH |
| Product Status | Active |
| Type / Construction | Toroidal |
| Shielding | Shielded |
| Mounting Type | Through Hole |
| Height - Seated (Max) | 0.310" (7.87mm) |
