Description
FIXED IND 26UH 1.48A 100 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PE-53824SNL.
PE-53824SNL has an inductance value of 26 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PE-53824SNL is rated for 1.48 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PE-53824SNL lists a DC resistance of 100mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PE-53824SNL uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PE-53824SNL to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 26 µH |
| Tolerance | ±20% |
| Current Rating | 1.48 A |
| DC Resistance (DCR) | 100mOhm |
| Operating Temperature | -40°C ~ 130°C |
| Dimensions | 0.570" L x 0.565" W (14.48mm x 14.35mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 26UH 1.48A 100 MOHM |
| Product Status | Active |
| Type / Construction | Toroidal |
| Shielding | Shielded |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.360" (9.14mm) |
