Description
FIXED IND 270NH 280MA 1.1 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PM0805-R27K.
PM0805-R27K has an inductance value of 270 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PM0805-R27K is rated for 280 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PM0805-R27K lists a DC resistance of 1.1Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PM0805-R27K uses a package or case of 0805 (2012 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PM0805-R27K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 270 nH |
| Tolerance | ±10% |
| Current Rating | 280 mA |
| DC Resistance (DCR) | 1.1Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.083" L x 0.059" W (2.10mm x 1.50mm) |
| Case / Size | 0805 (2012 Metric) |
| Package / Case | 0805 (2012 Metric) |
| Supplier | Bourns Inc. |
| Description | FIXED IND 270NH 280MA 1.1 OHM |
| Series | PM0805 |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 100MHz |
| Self Resonant Frequency | 800MHz |
| Inductance Test Frequency | 100 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0805 (2012 Metric) |
| Height - Seated (Max) | 0.059" (1.50mm) |
