Description
FIXED IND 220UH 210MA 10 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PM1008S-221M-RC.
PM1008S-221M-RC has an inductance value of 220 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PM1008S-221M-RC is rated for 210 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PM1008S-221M-RC lists a DC resistance of 10Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PM1008S-221M-RC uses a package or case of 1008 (2520 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PM1008S-221M-RC to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 220 µH |
| Tolerance | ±20% |
| Current Rating | 210 mA |
| DC Resistance (DCR) | 10Ohm Max |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.150" L x 0.150" W (3.81mm x 3.81mm) |
| Case / Size | 1008 (2520 Metric) |
| Package / Case | 1008 (2520 Metric) |
| Supplier | Bourns Inc. |
| Description | FIXED IND 220UH 210MA 10 OHM SMD |
| Series | PM1008S |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | 55 @ 1MHz |
| Self Resonant Frequency | 4.5MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 (2520 Metric) |
| Height - Seated (Max) | 0.108" (2.74mm) |
