Description
FIXED IND SURFACE MOUNT
Specifications
Dimensions
0.492" L x 0.492" W (12.50mm x 12.50mm)
Parameter Guide
Understand the key electrical and mechanical specifications for PM127SH-7R6Y-RC.
Package / Case
Nonstandard
PM127SH-7R6Y-RC uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PM127SH-7R6Y-RC to manufacturer, series, and broader datasheet collections.
Product Attributes
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND SURFACE MOUNT |
| Series | PM127SH |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.315" (8.00mm) |
