FIXED IND 150UH 280MA 2.6 OHM
| Inductance | 150 µH |
| Tolerance | ±30% |
| Current Rating | 280 mA |
| DC Resistance (DCR) | 2.6Ohm Max |
| saturationCurrent | 260mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.189" L x 0.189" W (4.80mm x 4.80mm) |
| Case / Size | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 150UH 280MA 2.6 OHM |
| Series | PM42S |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 14 @ 796kHz |
| selfResonantFreq | 10MHz |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.118" (3.00mm) |
| features | - |
