Description
FIXED IND 22UH 960MA 135 MOHM
Specifications
Inductance
22 µH
Current Rating
960 mA
DC Resistance (DCR)
135mOhm Max
Dimensions
0.276" L x 0.276" W (7.00mm x 7.00mm)
Product Attributes
Manufacturer Verified
Last verified: 6/11/2026| Inductance | 22 µH |
| Tolerance | ±20% |
| Current Rating | 960 mA |
| DC Resistance (DCR) | 135mOhm Max |
| saturationCurrent | 1.05A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.276" L x 0.276" W (7.00mm x 7.00mm) |
| Case / Size | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 22UH 960MA 135 MOHM |
| Series | PM7032S |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 20 @ 2.52MHz |
| selfResonantFreq | 29MHz |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.134" (3.40mm) |
| features | - |
