FIXED IND 1.5UH 30A 1.6 MOHM SMD
| Inductance | 1.5 µH |
| Tolerance | ±10% |
| Current Rating | 30 A |
| DC Resistance (DCR) | 1.6mOhm Max |
| saturationCurrent | - |
| Operating Temperature | -40°C ~ 155°C |
| Dimensions | 1.098" L x 0.780" W (27.90mm x 19.80mm) |
| Case / Size | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 1.5UH 30A 1.6 MOHM SMD |
| Series | PQ2614BLA |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | 60MHz |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.630" (16.00mm) |
| features | - |
