Description
FIXED IND 4.7UH 28A 2.5 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for PQ2617BHA-4R7K.
PQ2617BHA-4R7K has an inductance value of 4.7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
PQ2617BHA-4R7K is rated for 28 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
PQ2617BHA-4R7K lists a DC resistance of 2.5mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
PQ2617BHA-4R7K uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from PQ2617BHA-4R7K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 4.7 µH |
| Tolerance | ±10% |
| Current Rating | 28 A |
| DC Resistance (DCR) | 2.5mOhm Max |
| Saturation Current | 61.2A |
| Operating Temperature | -40°C ~ 155°C |
| Dimensions | 1.098" L x 0.780" W (27.90mm x 19.80mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 4.7UH 28A 2.5 MOHM SMD |
| Series | PQ2617BHA |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 30MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.748" (19.00mm) |
