Description
FIXED IND 10MH 84MA 33 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for RL875-103K.
RL875-103K has an inductance value of 10 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
RL875-103K is rated for 84 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
RL875-103K lists a DC resistance of 33Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
RL875-103K uses a package or case of Radial, Vertical Cylinder (Open). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from RL875-103K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 10 mH |
| Tolerance | ±10% |
| Current Rating | 84 mA |
| DC Resistance (DCR) | 33Ohm Max |
| Operating Temperature | -30°C ~ 100°C |
| Dimensions | 0.307" Dia (7.80mm) |
| Case / Size | Radial, Vertical Cylinder (Open) |
| Package / Case | Radial, Vertical Cylinder (Open) |
| Supplier | Bourns Inc. |
| Description | FIXED IND 10MH 84MA 33 OHM TH |
| Series | RL875 |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Height - Seated (Max) | 0.217" (5.50mm) |
