Description
FIXED IND 680UH 280MA 2.07 OHM
Specifications
Inductance
680 µH
Current Rating
280 mA
DC Resistance (DCR)
2.07Ohm Max
Dimensions
0.307" Dia (7.80mm)
Product Attributes
Manufacturer Verified
Last verified: 6/11/2026| Inductance | 680 µH |
| Tolerance | ±10% |
| Current Rating | 280 mA |
| DC Resistance (DCR) | 2.07Ohm Max |
| saturationCurrent | - |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.307" Dia (7.80mm) |
| Case / Size | Radial, Vertical Cylinder |
| Supplier | Bourns Inc. |
| Description | FIXED IND 680UH 280MA 2.07 OHM |
| Series | RL875S |
| productStatus | Obsolete |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 45 @ 796kHz |
| selfResonantFreq | 2MHz |
| ratings | - |
| testFrequency | 1 kHz |
| mountingType | Through Hole |
| supplierDevicePackage | - |
| heightMax | 0.295" (7.50mm) |
| features | - |
