SMRF1812-104K
Gowanda
Description
FIXED IND 1MH 71MA 40 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SMRF1812-104K.
SMRF1812-104K has an inductance value of 1 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SMRF1812-104K is rated for 71 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SMRF1812-104K lists a DC resistance of 40Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SMRF1812-104K uses a package or case of 1812 (4532 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SMRF1812-104K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1 mH |
| Tolerance | ±10% |
| Current Rating | 71 mA |
| DC Resistance (DCR) | 40Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.175" L x 0.126" W (4.45mm x 3.20mm) |
| Case / Size | 1812 (4532 Metric) |
| Package / Case | 1812 (4532 Metric) |
| Supplier | Gowanda |
| Description | FIXED IND 1MH 71MA 40 OHM SMD |
| Series | SMRF1812 |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 790kHz |
| Self Resonant Frequency | 2MHz |
| Inductance Test Frequency | 790 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1812 |
| Height - Seated (Max) | 0.138" (3.50mm) |
