Description
FIXED IND 180NH 757MA 350 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SMRF1812-180J.
SMRF1812-180J has an inductance value of 180 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SMRF1812-180J is rated for 757 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SMRF1812-180J lists a DC resistance of 350mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SMRF1812-180J uses a package or case of 1812 (4532 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SMRF1812-180J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 180 nH |
| Tolerance | ±5% |
| Current Rating | 757 mA |
| DC Resistance (DCR) | 350mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.175" L x 0.126" W (4.45mm x 3.20mm) |
| Case / Size | 1812 (4532 Metric) |
| Package / Case | 1812 (4532 Metric) |
| Supplier | Gowanda |
| Description | FIXED IND 180NH 757MA 350 MOHM |
| Series | SMRF1812 |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Iron Powder |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 25MHz |
| Self Resonant Frequency | 400MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1812 |
| Height - Seated (Max) | 0.138" (3.50mm) |
| Features | - |
