Description
FIXED IND 1.8UH 556MA 650 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SMRF1812-181KLF.
SMRF1812-181KLF has an inductance value of 1.8 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SMRF1812-181KLF is rated for 556 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SMRF1812-181KLF lists a DC resistance of 650mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SMRF1812-181KLF uses a package or case of 1812 (4532 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SMRF1812-181KLF to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.8 µH |
| Tolerance | ±10% |
| Current Rating | 556 mA |
| DC Resistance (DCR) | 650mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.175" L x 0.126" W (4.45mm x 3.20mm) |
| Case / Size | 1812 (4532 Metric) |
| Package / Case | 1812 (4532 Metric) |
| Supplier | Gowanda |
| Description | FIXED IND 1.8UH 556MA 650 MOHM |
| Series | SMRF1812 |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 50 @ 7.9MHz |
| Self Resonant Frequency | 60MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1812 |
| Height - Seated (Max) | 0.138" (3.50mm) |
| Features | - |
