Description
FIXED IND 560NH 409MA 1.2 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SMRF1812-560JLF.
SMRF1812-560JLF has an inductance value of 560 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SMRF1812-560JLF is rated for 409 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SMRF1812-560JLF lists a DC resistance of 1.2Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SMRF1812-560JLF uses a package or case of 1812 (4532 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SMRF1812-560JLF to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 560 nH |
| Tolerance | ±5% |
| Current Rating | 409 mA |
| DC Resistance (DCR) | 1.2Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.175" L x 0.126" W (4.45mm x 3.20mm) |
| Case / Size | 1812 (4532 Metric) |
| Package / Case | 1812 (4532 Metric) |
| Supplier | Gowanda |
| Description | FIXED IND 560NH 409MA 1.2 OHM |
| Series | SMRF1812 |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Iron Powder |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 25MHz |
| Self Resonant Frequency | 170MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1812 |
| Height - Seated (Max) | 0.138" (3.50mm) |
| Features | - |
