Description
FIXED IND 560NH 6.7A 27.6 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRP0410F-R56M.
SRP0410F-R56M has an inductance value of 560 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRP0410F-R56M is rated for 6.7 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRP0410F-R56M lists a DC resistance of 27.6mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRP0410F-R56M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRP0410F-R56M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 560 nH |
| Tolerance | ±20% |
| Current Rating | 6.7 A |
| DC Resistance (DCR) | 27.6mOhm Max |
| Saturation Current | 7A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.169" L x 0.161" W (4.30mm x 4.10mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 560NH 6.7A 27.6 MOHM |
| Series | SRP0410F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Metal |
| Shielding | Shielded |
| Q @ Frequency | 5 @ 100MHz |
| Self Resonant Frequency | 100MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.039" (1.00mm) |
