Description
FIXED IND 3.2UH 8A 10.4 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRP1045-3R2M.
SRP1045-3R2M has an inductance value of 3.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRP1045-3R2M is rated for 8 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRP1045-3R2M lists a DC resistance of 10.4mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRP1045-3R2M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRP1045-3R2M to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 3.2 µH |
| Tolerance | ±20% |
| Current Rating | 8 A |
| DC Resistance (DCR) | 10.4mOhm Max |
| Saturation Current | 8A |
| Operating Temperature | -55°C ~ 150°C |
| Dimensions | 0.433" L x 0.368" W (11.00mm x 9.35mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 3.2UH 8A 10.4 MOHM SMD |
| Series | SRP1045 |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.189" (4.80mm) |
