Description
FIXED IND 600NH 16A 2.5 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRP1205-R60Y.
SRP1205-R60Y has an inductance value of 600 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRP1205-R60Y is rated for 16 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRP1205-R60Y lists a DC resistance of 2.5mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRP1205-R60Y uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRP1205-R60Y to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 600 nH |
| Tolerance | ±25% |
| Current Rating | 16 A |
| DC Resistance (DCR) | 2.5mOhm Max |
| Saturation Current | 27A |
| Operating Temperature | -55°C ~ 150°C |
| Dimensions | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 600NH 16A 2.5 MOHM SMD |
| Series | SRP1205 |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 95MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.197" (5.00mm) |
