Description
FIXED IND 390NH 42A 0.95 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRP1245A-R39M.
SRP1245A-R39M has an inductance value of 390 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRP1245A-R39M is rated for 42 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRP1245A-R39M lists a DC resistance of 0.95mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRP1245A-R39M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRP1245A-R39M to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 390 nH |
| Tolerance | ±20% |
| Current Rating | 42 A |
| DC Resistance (DCR) | 0.95mOhm Max |
| Saturation Current | 70A |
| Operating Temperature | -40°C ~ 150°C |
| Dimensions | 0.531" L x 0.492" W (13.50mm x 12.50mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 390NH 42A 0.95 MOHM |
| Series | SRP1245A |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Carbonyl Powder |
| Shielding | Shielded |
| Q @ Frequency | 15 @ 100kHz |
| Self Resonant Frequency | 78MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.197" (5.00mm) |
