FIXED IND 120UH 530MA 720 MOHM
| Inductance | 120 µH |
| Tolerance | ±20% |
| Current Rating | 530 mA |
| DC Resistance (DCR) | 720mOhm Max |
| saturationCurrent | 550mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.287" L x 0.287" W (7.30mm x 7.30mm) |
| Case / Size | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 120UH 530MA 720 MOHM |
| Series | SRR0735A |
| productStatus | Not For New Designs |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | AEC-Q200 |
| testFrequency | 1 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.146" (3.70mm) |
| features | - |
