Description
FIXED IND 180UH 430MA 1.15 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRR0735A-181M.
SRR0735A-181M has an inductance value of 180 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRR0735A-181M is rated for 430 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRR0735A-181M lists a DC resistance of 1.15Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRR0735A-181M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRR0735A-181M to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 180 µH |
| Tolerance | ±20% |
| Current Rating | 430 mA |
| DC Resistance (DCR) | 1.15Ohm Max |
| Saturation Current | 450mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.287" L x 0.287" W (7.30mm x 7.30mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 180UH 430MA 1.15 OHM |
| Series | SRR0735A |
| Product Status | Not For New Designs |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.146" (3.70mm) |
