Description
FIXED IND 820UH 190MA 5.2 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRR0735HA-821M.
SRR0735HA-821M has an inductance value of 820 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRR0735HA-821M is rated for 190 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRR0735HA-821M lists a DC resistance of 5.2Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRR0735HA-821M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRR0735HA-821M to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 820 µH |
| Tolerance | ±20% |
| Current Rating | 190 mA |
| DC Resistance (DCR) | 5.2Ohm Max |
| Saturation Current | 210mA |
| Operating Temperature | -55°C ~ 150°C |
| Dimensions | 0.287" L x 0.287" W (7.30mm x 7.30mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 820UH 190MA 5.2 OHM |
| Series | SRR0735HA |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.146" (3.70mm) |
