Description
FIXED IND 25UH SURFACE MOUNT
Specifications
Inductance
25 µH
Dimensions
0.500" L x 0.500" W (12.70mm x 12.70mm)
Parameter Guide
Understand the key electrical and mechanical specifications for SRR1205-250ML.
Inductance
25 µH
SRR1205-250ML has an inductance value of 25 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Package / Case
Nonstandard
SRR1205-250ML uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRR1205-250ML to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 25 µH |
| Tolerance | ±20% |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.500" L x 0.500" W (12.70mm x 12.70mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 25UH SURFACE MOUNT |
| Series | SRR1205 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.217" (5.50mm) |
