FIXED IND 820UH 730MA 1.5 OHM
| Inductance | 820 µH |
| Tolerance | ±10% |
| Current Rating | 730 mA |
| DC Resistance (DCR) | 1.5Ohm Max |
| saturationCurrent | 630mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Case / Size | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 820UH 730MA 1.5 OHM |
| Series | SRR1260A |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 20 @ 796kHz |
| selfResonantFreq | 2MHz |
| ratings | AEC-Q200 |
| testFrequency | 1 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.256" (6.50mm) |
| features | - |
