Description
FIXED IND 7UH SURFACE MOUNT
Specifications
Inductance
7 µH
Dimensions
0.720" L x 0.551" W (18.30mm x 14.00mm)
Parameter Guide
Understand the key electrical and mechanical specifications for SRR1806-7R0M.
Inductance
7 µH
SRR1806-7R0M has an inductance value of 7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Package / Case
Nonstandard
SRR1806-7R0M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRR1806-7R0M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 7 µH |
| Tolerance | ±20% |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.720" L x 0.551" W (18.30mm x 14.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 7UH SURFACE MOUNT |
| Series | SRR1806 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.280" (7.10mm) |
