Description
FIXED IND 8.2UH 2.3A 63 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRR5828A-8R2Y.
SRR5828A-8R2Y has an inductance value of 8.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRR5828A-8R2Y is rated for 2.3 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRR5828A-8R2Y lists a DC resistance of 63mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRR5828A-8R2Y uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRR5828A-8R2Y to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 8.2 µH |
| Tolerance | ±30% |
| Current Rating | 2.3 A |
| DC Resistance (DCR) | 63mOhm Max |
| Saturation Current | 1.62A |
| Operating Temperature | -40°C ~ 150°C |
| Dimensions | 0.228" L x 0.228" W (5.80mm x 5.80mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 8.2UH 2.3A 63 MOHM SMD |
| Series | SRR5828A |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 37MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.126" (3.20mm) |
