Description
FIXED IND 12UH 3.2A 55 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRR6838A-120M.
SRR6838A-120M has an inductance value of 12 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRR6838A-120M is rated for 3.2 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRR6838A-120M lists a DC resistance of 55mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRR6838A-120M uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRR6838A-120M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 12 µH |
| Tolerance | ±20% |
| Current Rating | 3.2 A |
| DC Resistance (DCR) | 55mOhm Max |
| Saturation Current | 1.6A |
| Operating Temperature | -55°C ~ 150°C |
| Dimensions | 0.268" L x 0.268" W (6.80mm x 6.80mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 12UH 3.2A 55 MOHM SMD |
| Series | SRR6838A |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 26MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.165" (4.20mm) |
