Description
FIXED IND 5UH 4.5A 25 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRR6838A-5R0Y.
SRR6838A-5R0Y has an inductance value of 5 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRR6838A-5R0Y is rated for 4.5 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRR6838A-5R0Y lists a DC resistance of 25mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRR6838A-5R0Y uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRR6838A-5R0Y to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 5 µH |
| Tolerance | ±30% |
| Current Rating | 4.5 A |
| DC Resistance (DCR) | 25mOhm Max |
| Saturation Current | 2.63A |
| Operating Temperature | -55°C ~ 150°C |
| Dimensions | 0.268" L x 0.268" W (6.80mm x 6.80mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 5UH 4.5A 25 MOHM SMD |
| Series | SRR6838A |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Self Resonant Frequency | 55MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.165" (4.20mm) |
