FIXED IND 47UH 1.3A 230 MOHM SMD
| Inductance | 47 µH |
| Tolerance | ±30% |
| Current Rating | 1.3 A |
| DC Resistance (DCR) | 230mOhm Max |
| saturationCurrent | 1.1A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.394" L x 0.394" W (10.00mm x 10.00mm) |
| Case / Size | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 47UH 1.3A 230 MOHM SMD |
| Series | SRU1028A |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 20 @ 2.52MHz |
| selfResonantFreq | 11MHz |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.122" (3.10mm) |
| features | - |
