Description
FIXED IND 220UH 650MA 740 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRU1038A-221Y.
SRU1038A-221Y has an inductance value of 220 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRU1038A-221Y is rated for 650 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRU1038A-221Y lists a DC resistance of 740mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRU1038A-221Y uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRU1038A-221Y to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 220 µH |
| Tolerance | ±30% |
| Current Rating | 650 mA |
| DC Resistance (DCR) | 740mOhm Max |
| Saturation Current | 650mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.394" L x 0.394" W (10.00mm x 10.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 220UH 650MA 740 MOHM |
| Series | SRU1038A |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | 22 @ 796kHz |
| Self Resonant Frequency | 4MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.161" (4.10mm) |
