Description
FIXED IND 2.2UH 800MA 145 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRU3009-2R2Y.
SRU3009-2R2Y has an inductance value of 2.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRU3009-2R2Y is rated for 800 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRU3009-2R2Y lists a DC resistance of 145mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRU3009-2R2Y uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRU3009-2R2Y to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 2.2 µH |
| Tolerance | ±30% |
| Current Rating | 800 mA |
| DC Resistance (DCR) | 145mOhm Max |
| Saturation Current | 850mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.138" L x 0.130" W (3.50mm x 3.30mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 2.2UH 800MA 145 MOHM |
| Series | SRU3009 |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | 8.5 @ 7.96MHz |
| Self Resonant Frequency | 150MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.041" (1.05mm) |
