Description
FIXED IND 22UH 320MA 875 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SRU3014-220Y.
SRU3014-220Y has an inductance value of 22 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SRU3014-220Y is rated for 320 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SRU3014-220Y lists a DC resistance of 875mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SRU3014-220Y uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SRU3014-220Y to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 22 µH |
| Tolerance | ±30% |
| Current Rating | 320 mA |
| DC Resistance (DCR) | 875mOhm Max |
| Saturation Current | 360mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.138" L x 0.130" W (3.50mm x 3.30mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 22UH 320MA 875 MOHM |
| Series | SRU3014 |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | 35 @ 2.52MHz |
| Self Resonant Frequency | 25MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.063" (1.60mm) |
