FIXED IND 100UH 200MA 1.6 OHM
| Inductance | 100 µH |
| Tolerance | ±30% |
| Current Rating | 200 mA |
| DC Resistance (DCR) | 1.6Ohm |
| saturationCurrent | 180mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.205" L x 0.205" W (5.20mm x 5.20mm) |
| Case / Size | Nonstandard |
| Supplier | Bourns Inc. |
| Description | FIXED IND 100UH 200MA 1.6 OHM |
| Series | SRU5011 |
| productStatus | Obsolete |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 30 @ 796kHz |
| selfResonantFreq | 15MHz |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.047" (1.20mm) |
| features | - |
