FIXED IND 10UH 3.5A 48 MOHM SMD
| Inductance | 10 µH |
| Tolerance | ±30% |
| Current Rating | 3.5 A |
| DC Resistance (DCR) | 48mOhm Max |
| saturationCurrent | 3.3A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.315" L x 0.315" W (8.00mm x 8.00mm) |
| Case / Size | 4-SMD |
| Supplier | Bourns Inc. |
| Description | FIXED IND 10UH 3.5A 48 MOHM SMD |
| Series | SRU8045A |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | 16 @ 2.52MHz |
| selfResonantFreq | 18MHz |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.189" (4.80mm) |
| features | - |
