Description
IND 4.7UH 7.7MOHM 17A
Specifications
Inductance
4.7 µH
Current Rating
17 A
DC Resistance (DCR)
7.7 mOhm Max
Parameter Guide
Understand the key electrical and mechanical specifications for TMPA1265HTV-4R7MN-D.
Inductance
4.7 µH
TMPA1265HTV-4R7MN-D has an inductance value of 4.7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Current Rating
17 A
TMPA1265HTV-4R7MN-D is rated for 17 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DC Resistance (DCR)
7.7 mOhm Max
TMPA1265HTV-4R7MN-D lists a DC resistance of 7.7 mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from TMPA1265HTV-4R7MN-D to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 4.7 µH |
| Tolerance | ±20% |
| Current Rating | 17 A |
| DC Resistance (DCR) | 7.7 mOhm Max |
| Saturation Current | 20 A Max |
| Supplier | TAI-TECH |
| Description | IND 4.7UH 7.7MOHM 17A |
| Product Status | Active |
| Inductance Test Frequency | 100 kHz |
