Description
FIXED IND 6.8UH 1.08A 192 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for VLS3015CX-6R8M-H.
VLS3015CX-6R8M-H has an inductance value of 6.8 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
VLS3015CX-6R8M-H is rated for 1.08 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
VLS3015CX-6R8M-H lists a DC resistance of 192mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
VLS3015CX-6R8M-H uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from VLS3015CX-6R8M-H to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 6.8 µH |
| Tolerance | ±20% |
| Current Rating | 1.08 A |
| DC Resistance (DCR) | 192mOhm Max |
| Saturation Current | 950mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.118" L x 0.118" W (3.00mm x 3.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | TDK |
| Description | FIXED IND 6.8UH 1.08A 192 MOHM |
| Series | VLS-CX-H |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 1 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 3015 |
| Height - Seated (Max) | 0.059" (1.50mm) |
