Description
FIXED IND 100UH 40MA 4 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for WNLU252018RV-101M.
WNLU252018RV-101M has an inductance value of 100 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
WNLU252018RV-101M is rated for 40 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
WNLU252018RV-101M lists a DC resistance of 4Ohm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
WNLU252018RV-101M uses a package or case of 1008 (2520 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from WNLU252018RV-101M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 100 µH |
| Tolerance | ±20% |
| Current Rating | 40 mA |
| DC Resistance (DCR) | 4Ohm |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.102" L x 0.079" W (2.60mm x 2.00mm) |
| Case / Size | 1008 (2520 Metric) |
| Package / Case | 1008 (2520 Metric) |
| Supplier | TAI-TECH |
| Description | FIXED IND 100UH 40MA 4 OHM SMD |
| Series | WNLU252018RV |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 796 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.079" (2.00mm) |
