Description
FIXED IND 22UH 105MA 1 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for WNLU252018RV-220M.
WNLU252018RV-220M has an inductance value of 22 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
WNLU252018RV-220M is rated for 105 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
WNLU252018RV-220M lists a DC resistance of 1Ohm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
WNLU252018RV-220M uses a package or case of 1008 (2520 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from WNLU252018RV-220M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 22 µH |
| Tolerance | ±20% |
| Current Rating | 105 mA |
| DC Resistance (DCR) | 1Ohm |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.102" L x 0.079" W (2.60mm x 2.00mm) |
| Case / Size | 1008 (2520 Metric) |
| Package / Case | 1008 (2520 Metric) |
| Supplier | TAI-TECH |
| Description | FIXED IND 22UH 105MA 1 OHM SMD |
| Series | WNLU252018RV |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 2.52 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.079" (2.00mm) |
