Description
FIXED IND 3.3UH 280MA 200 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for WNLU252018RV-3R3M.
WNLU252018RV-3R3M has an inductance value of 3.3 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
WNLU252018RV-3R3M is rated for 280 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
WNLU252018RV-3R3M lists a DC resistance of 200mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
WNLU252018RV-3R3M uses a package or case of 1008 (2520 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from WNLU252018RV-3R3M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3.3 µH |
| Tolerance | ±20% |
| Current Rating | 280 mA |
| DC Resistance (DCR) | 200mOhm |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.102" L x 0.079" W (2.60mm x 2.00mm) |
| Case / Size | 1008 (2520 Metric) |
| Package / Case | 1008 (2520 Metric) |
| Supplier | TAI-TECH |
| Description | FIXED IND 3.3UH 280MA 200 MOHM |
| Series | WNLU252018RV |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 7.96 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.079" (2.00mm) |
