Description
FIXED IND 12UH 126MA 3 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 0819-50J.
0819-50J has an inductance value of 12 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
0819-50J is rated for 126 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
0819-50J lists a DC resistance of 3Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
0819-50J uses a package or case of Through Hole. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 0819-50J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 12 µH |
| Tolerance | ±5% |
| Current Rating | 126 mA |
| DC Resistance (DCR) | 3Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | - |
| Case / Size | Through Hole |
| Package / Case | Through Hole |
| Supplier | Delevan |
| Description | FIXED IND 12UH 126MA 3 OHM TH |
| Series | 819 |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 2.5MHz |
| Self Resonant Frequency | 31MHz |
| Ratings | - |
| Inductance Test Frequency | 2.5 MHz |
| Mounting Type | - |
| Supplier Device Package | Axial |
| Height - Seated (Max) | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) |
| Features | - |
